| Gross vehicle mass | 4,990 (kg) |
|---|---|
| Payload | 2,200 (kg) |
| Overall Dimension | 5,490 x 1,950 x 2,850 (mm) |
| Max. power | 105 (77) / 3,200 (Ps(kW) / rpm) |
| Emission | Euro 4 |
| Manufacturers Name | Isuzu Vietnam Co., Ltd |
| Manufacturers Address | 695 Quang Trung Street, Ward 8, Go Vap District, Ho Chi Minh City |
| Origin | Vietnam |
| Certification number of approval (TA) | 0009/VAQ09 – 01/22 – 00 |
| Suggested retail price | 709,854,545 |
* Applied for cabin chassis and freezer body. (Price is included VAT)
| Gross vehicle mass | Kg | 4,990 |
| Kerb mass | Kg | 2,595 |
| Payload | Kg | 2,200 |
| Number of seats | Person | 3 |
| Overall Dimension (OAL x OW X OH) | mm | 5,490 x 1,950 x 2,850 |
| Body’s external (LxWxH) | mm | 3,700 x 1,950 x 1,950 |
| Body’s internal (LxWxH) | mm | 3,520 x 1,810 x 1,780 |
| Model | 4JH1E4NC | |
| Systems | Common rail, turbo-intercooler, EGR & DOC | |
| Emission | EURO 4 | |
| Max. power | Ps(kW) / rpm | 105 (77) / 3,200 |
| Max. torque | N.m(kgf.m) / rpm | 230 (23) / 1,400 ~ 3,200 |
| Transmission | N.m(kgf.m) / rpm | MSB5S 5 Forward & 1 Reverse |
| Steering system | Recirculating ball with hydraulic assisted |
| Suspension system front – rear | Dependent, leafspring, shock absorber |
| Brake system front – rear | Drum, hydraulic with vacuum servo assistance, dual circuilt |
| Tire size front – rear | 7.00 – 15 12PR |
| Generator | 12V-90A |
| Interior and exterior panel skin | Imported FRP-GRP |
| Panel Insulation | XPS |
| Panel thickness | Side wall: 65 mm Front wall: 65 mm Rear door: 65 mm Roof wall: 80 mm Floor panel: 85 mm |
| Floor | Corrugated 304 stainless steel |
| Rear door frame | Alloy Aluminum |
| Side door | Standard |
| Rack Cab Guard & Ladder | Standard 304-Stainless steel |
| Door handle | 304-Stainless steel |
| Hinges | Aluminium |
| Profiles (top, bottom, front) | Aluminium |
| Corner-lights | 04 lights |
| Mud guard and side fender | Standard |
| Rear step | Standard |
| Side LED lights | Standard (06 pcs) |
| Ceiling light | Standard |
| Warning buzzer | Standard |
| Refrigeration unit | Thermal Master T-1400 (Korea) |
| Power | 1,900 Walt |
| Gas type | R404a |
| Temperature | -18°C |
*Specifications and equipment are subjects to change without prior notice
